NMM Particle Grinding Ceramic Industrial Bead Mill Turbine Grinding System

Boyee (Shenzhen) Industrial Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap NMM Particle Grinding Ceramic Industrial Bead Mill Turbine Grinding System from wholesalers

    Buy cheap NMM Particle Grinding Ceramic Industrial Bead Mill Turbine Grinding System from wholesalers
    • Buy cheap NMM Particle Grinding Ceramic Industrial Bead Mill Turbine Grinding System from wholesalers

    NMM Particle Grinding Ceramic Industrial Bead Mill Turbine Grinding System

    Ask Lasest Price
    Brand Name : Boyee
    Certification : CE ISO
    Supply Ability : 20 Set/Sets per Month that depends on cust need
    Price : Negotiable
    Model Number : NMM
    • Product Details
    • Company Profile

    NMM Particle Grinding Ceramic Industrial Bead Mill Turbine Grinding System

    Nano particle grinding mill machine with Turbine grinding system
    Product Description

    The clear,straightforward design with integrated hoses and pipes results in simplified operation,prevents contamination and,at the same time,means considerably less effort is required for cleaning,The spatial separation of media-converying fitting for cooling water,compressed air or mechanical seal buffer fluid ensures a high level of operational safety and allows safe access ,even during operation.


    Product Features

    • Patented Turbine grinding system and Ceramic DISK classifier separation system combination .Focused on True comminution ,do not destroy material property ;high Dispersion ability ,Never agglomeration .
    • Material shape is close to sphericity after grinding
    • Handy Assembled classifier ,Easy to adjust separation system gap satisfied different size grinding medias
    • Independent Developed Double mechanical seal compatible with grinding tank definitely ,No worry of leakage
    • Pressure induction protective device and electric protective system, secure and reliable
    • Full-ceramic grinding tools to avoid metallic pollution

    Product Application

    It is widely used to produce battery material,printing inks,ceramic material,microelectronics,semiconductor,cosmetics,

    pharmaceuticals,agrochemical,paper making,food,life science,paint,inks,fuel catalyst,lon echange products,metallic oxide,pigments,etc.


    Additional Optimizations of the Grinding Chamber

    Further modifications in the entire grinding chamber have been designed, in order to make sure that the innovations mentioned above complement each other:

    • Optimized geometry for the flow in the product inlet
    • Newly developed central degassing unit which improves the processing of foaming products
    • New conception of all mechanical machine parts, according to the highest standards

    ModelVolume (L)Motor Power (KW)Medium Size (mm)Weight (KG)Dimension(mm)
    NMM-101018.50.3-112801800*1200*1550
    NMM-3030450.3-118501800*1300*1800
    NMM-6058750.3-124803290*1478*1950
    NMM-909875-900.3-130503290*1478*1950
    NMM-150120-1801600.3-152804500*1700*2400

    NMM Particle Grinding Ceramic Industrial Bead Mill Turbine Grinding SystemNMM Particle Grinding Ceramic Industrial Bead Mill Turbine Grinding System


    Pre-Sales Service

    * Inquiry and consulting support.

    * Sample testing support.

    * View our Factory.

    After-Sales Service

    * Training how to instal the machine, training how to use the machine.

    * Engineers available to service machinery overseas.

    Packaging
    Size1100*550*1650
    Weight80kg
    Packaging DetailsThe normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
