10L bead mill machine for Coating,Paint,Ink,Nano abrasive

Product Description

Product Application

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc. Beverage bottle, cosmetic bottle, medicine bottle, jar etc.

The new generation of mills was consistently designed for an increase of the throughput. The increase of the possible throughput leads to more flexibility in the choice of process parameters.

In the circulation process, high throughputs usually have a positive influence on the production capacity. Experiments in our laboratory have already shown that much higher through­ puts can be realized with the new turbine grinding system . Besides an increase in the production capacity, a higher num­ ber of circulations can also lead to a narrower particle size distribution.

Better Ability to run Highly Viscous Products

The combination of an optimized circulation of the beads and a much higher cross-sectional area for flow through the screen. results in a great improvement in the ability to process highly viscous products.

Here the directed axial flow of the beads over the screen surface removes coarse particles from the surface of the screen, allowing a better flow through the screen. The free flow through the screen is not reduced, because this self-cleaning effect prevents block­ ages. An increase in the pressure, which can take place with highly viscous products, is therefore avoided.

Product Application

• Liquid Crystal Display LCDCeramic Multilayer Capacitors MLCC Photo Catalysts
• Pesticides Fertilizer
• Printing Inks
• Pigments / Dyes
• Paint
• Ores / Minerals / Metals

Model	Volume (L)	Motor Power (KW)	Medium Size (mm)	Weight (KG)	Dimension(mm)
NMM-10	10	18.5	0.3-1	1280	1800*1200*1550
NMM-30	30	45	0.3-1	1850	1800*1300*1800
NMM-60	58	75	0.3-1	2480	3290*1478*1950
NMM-90	98	75-90	0.3-1	3050	3290*1478*1950
NMM-150	120-180	160	0.3-1	5280	4500*1700*2400

Boyee is a global leading enterprise headquartered in Shenzhen, specializing in providing intelligent manufacturing equipment, automated production line solutions, and smart factories for nano-material customers. Since its establishment in 2004, Boyee has focused on wet grinding and dispersion technology for over 20 years. With its strong R&D capabilities and technical accumulation, Boyee has successfully built a top-notch expert R&D team consisting of more than 50 post-doctoral and overseas master's degree holders. Through 8 technological innovations, Boyee has accumulated over 80 patented inventions, showcasing its outstanding strength in the field of nano-material technology.

The products and services involve various industries such as new energy battery cathode and anode materials, semiconductors, ink coatings, food, pharmaceuticals, cosmetics, and chemical industries. As a strategic partner of top global material companies, Boyee has been committed to the technological application of new materials. It has established a grinding and dispersion technology research center to help companies solve production challenges and technical issues in processing, and assist customers in achieving the transition from laboratory research to industrial production.

In terms of global business layout, Boyee has offices in multiple countries overseas, including South Korea, the United Kingdom, and Japan. Its business covers more than 50 countries and regions worldwide. Driven by technological innovation and product optimization, Boyee provides customers with more efficient and intelligent manufacturing solutions, aiming to become a leader in the global nano-material intelligent manufacturing field.
